Integra DSX-3

Описание Integra DSX-3

Тонкопрофильный AV-ресивер 5.1 с AirPlay, Bluetooth, WiFi.

AMPLIFIER
Number of Channels 5.1
POWER (4 Ω 1 kHz, 1% THD, 1 CH Driven) 80 Watts
Amplifier Frequency Response 10 Hz — 40 kHz
Continuous 6 Ω Rated ✓
Low Impedance Drive- Certified 4 Ω ✓
Hand Selected Parts to Ensure Low Impedance Performance: Custom- Audio Tuned
Discrete Output Stages for All Channels ✓
All Channels Equal Power Output ✓
Ultra Efficient Class-D Design ✓

PROCESSING
Dolby Atmos and Dolby Surround ✓
Dolby TrueHD ✓
DTS:X and DTS Neural:X ✓
DTS-HD Master Audio ✓
AccuEQ Automatic Room Calibration: Advanced w/AccuReflex
GAME Surround Modes (Rock, Action, Sports, Role Play) ✓
32-Bit DSP Chip for Advanced Processing ✓
Ultra-Low-Jitter Circuitry to Improve Audio ✓
Adjustable Crossover by Channel Pair 40/45/50/55/60/70/80/90/100/110/120/130/150/180/200 Hz
Accurate Speaker Distance Setting 0.1 — foot
A/V Sync Delay (by Source) -100 to +500 ms

CONNECTIVITY
HDMI Inputs / Output(s) 4 / 1
4K / 60 Hz 4:4:4 Colorspace Support ✓
HDCP 2.2 Copy-Protection Compatibility ✓
HDMI Support for BT.2020 ✓
HDMI Support for 3D, Audio Return Channel and CEC ✓
HDMI Support for Deep Color, x.v.Color, LipSync ✓
HDMI Support for DVD-Audio, SACD, Multichannel PCM ✓
Google Chromecast built-in ✓
Google Assistant (Voice Control) ✓
Analog to HDMI Upconversion From 480i / 576i
4K Upscaling from 1080p: via HDMI
Digital Audio Inputs (COAX / OPT) 1 / 1
Analog Audio Inputs 3
Phono Input ✓
Subwoofer Outputs 1
Speaker Output for Passive Subwoofer Support ✓
3.5 mm Headphone Output ✓

NETWORK / USB
FlareConnect Wireless Multi-Room Audio Streaming Technology ✓
DTS Play-Fi ✓
DTS Play-Fi App for iOS and Android: Integra Music Control
App Control via iOS and Android-Powered Devices: Integra Control Pro
Apple Airplay ✓
iPod / iPhone / iPad Ready ✓
Home Network Music Streaming ✓
TIDAL High Fidelity Music Streaming ✓
Pandora ✓
Spotify ✓
Spotify Connect ✓
TuneIn Radio ✓
Deezer ✓
DSD Support 2.8, 5.6 MHz
Dolby TrueHD Support ✓
Apple Lossless (ALAC) Support ✓
WAV Support ✓
AIFF Support ✓
DSDIFF Support ✓
FLAC Support ✓
MP3 Support ✓
USB Input for Streaming Audio ✓
WiFi Certified: IEEE 802.11 a/b/g/n, 5 Ghz / 2.4 Ghz
Bluetooth: Built-in
Firmware Updates via Network and USB ✓

INTEGRATION ACCESS
Bi-directional Ethernet Control Port ✓
Rear Panel IR Input / Output: 1 / 0
RIHD (Remote Interactive over HDMI) ✓

MISCELLANEOUS
GUI for Setup Menu ✓ (Advanced HD)
Quick Setup Menu ✓
Input Name Edit: Fully Customizable
HDMI Standby «Through» Mode: Assignable
Dealer Settings Memory Store & Recall Function ✓
Screensaver Function ✓ (Advanced)
Hybrid Standby to Reduce Power Consumption ✓
Smart Grid Ready ✓

AMPLIFIER SECTION
Power Output (4 Ω, 1 kHz, 1% THD, 2 Channels Driven, FTC) 80W / Channel (4 Ω)
Input Sensitivity and Impedance 200 mV / 47 k-Ω (LINE), 6 mV / 47 k-Ω (Phono MM)
Rated RCA Output Level and Impedance 1 Vrms / 470 Ω (Subwoofer Pre Out)
Phono Overload 30 mV (MM 1 kHz, 1%)
Frequency Response 10 Hz — 40 kHz / +1 dB-3 dB
Tone Control ±10dB, 90 Hz (Bass), ±10dB, 7.5 kHz (Treble)
Signal-to-Noise Ratio 80 dB (IHF-A, Line), 70 dB (IHF-A, Phono)
Speaker Impedance 4 Ω — 8 Ω

TUNER SECTION
Tuning Frequency Range FM 87.5 MHz — 107.9 MHz
FM Preset Memory 40 Stations

GENERAL
Power Supply AC 100–240 V~, 50 / 60 Hz
Power Consumption 60 W
Stand-by Power Consumption 0.2 W
